› High-load Li-ion cells
› At east 250W, 20A constant load
› 14.4V, 270Wh capacity
› 6A super fast charging
› D-tap output socket
› 4-level LED power indicator
› V-mount connection
› Multiple circuit protections

250W/20A High-Load
Even only 1% capacity remains, S-8183S+ still can output at least 250W/20A high load, for high power equipment like cine cameras and cine lights, and will not reduce battery life during long time high power output.

270Wh High Capacity
Updated from S-8183S, the S-8183S+ provides 270Wh/18.75Ah higher capacity, to prolong the running time on equipments.

6A Fast Charging
S-8183S+ supports 6A fast charging, to save more than 50% charging time, can be charged from 0 to 80% after 2.5 hours, and fully charged within 3.8 hours.

Build-in D-tap DC Output Socket
A D-tap DC output socket is equipped on the top side of S-8183S+ battery, for DC14.4V (Nominate) connection, such as on-camera lights, monitors, wireless transmitter, etc.
The Max Power from D-tap is 120W, 10A.

4-level LED Power Indicator
On the side of the battery, there’re 4-level LED power indicators to check the battery remaining capacity. You can get a quick view of capacity before using.
Nominal Voltage |
14.4V |
Capacity |
270Wh/18.75Ah |
Max output power |
In total:250W |
Electrodes:250W,20A | |
D-tap:120W,10A | |
Mount Type |
V-mount |
Charging Temperature |
0-40°C |
Discharging Temperature | -20°C-50°C (Capacity and Max Load may decrease when operating below 0°) |
Net weight |
Approx 1.3kg |
Dimensions |
165×90×66mm |
